CellarPro CP 4200VSX Wine Cellar Cooling Unit
Description
Designed for external installations, CellarPro engineered the 4200VSx-ECX cooling unit to provide maximum cooling power and adjustable humidity control for cellars up to 1,000 cubic feet. 4200VSx-ECX units are built with high-output Danfoss compressors and oversized coils for maximum performance in high-temperature environments up to 110F. These units also feature variable-speed fans with a low setting for super-quiet operation when conditions permit. Beginning with the 4200VSi cooling unit for interior installations, we've added to the 4200VSx-ECX an exterior weather hood, cold-temperature compressor heater, coated condenser coils, double-powder coated exterior case, reusable aluminum filter and exterior-grade power cord.
TECHNICAL SPECS
Weight: 149 lbs
Power/Rating:
115V AC / 60 Hz
Compressor Amps:
- Common dedicated 15-amp circuit is required to power the unit.
- Startup: 42.0 Amps
- Unit Amp Rating: 10.9 Amps (high fan speed)
- Total Watts: 578 (med fan speed)
BTUH @ 55F:
- Low Fan Speed: 3282
- Medium Fan Speed: 3617
- High Fan Speed: 3938
- 1/2 Ton Nominal
Additional Information
Dimensions - 14 1/2w x 27 3/5d x 19 7/10h (in)
Although the cooling units are rated for various size rooms, the thermal load may require a larger sized cooling unit. Thermal load may be affected by glass in the cellar, room positioning or other factors. Please let a Rosehill Wine Cellar rep make some suggestions for you if needed.
3938 SENSIBLE BTUH @ 55F.
CellarPro's 4200VSx-ECX cooling units (2/5 Ton Nominal) are engineered for external installations from 20F to 110F in residential and commercial wine cellars up to 1,000* cubic feet.
Shipping Information
Large Item Shipping: Additional Shipping charges may be charged for accessory items ordered on their own without the cooling unit. Rosehill Reserves the right to contact you should shipping charges end up substantially higher than advertised on our website. You will have an opportunity to not complete your order at that time.
For CAD customers - Shipping Charges for importation, brokerage, duties are extra might be extra, however you will be contact by a Rosehill Customer Service Representative to discuss it further. Local delivery included.
Warranty
A limited 2-year product warranty is offered entire system from date of purchase.
Cellar Pro Standard Warranty
IMPORTANT NOTE: Be sure to have the installing technician complete the CellarPro checklist upon installation. You will then send this to Cellar Pro to activate your warranty.
