CellarPro 1800XT Wine Cellar Cooling Unit

CellarPro engineered the 1800XT-ECX cooling unit for spaces that need extra BTUH and cooling capacity because of warm environments and/or the demands of a commercial establishment. 1800XT-ECX units are more powerful than CellarPro 1800QTL and 1800QT units.

Dimensions:

18" W x 10.5" H x 16.5" D

Although the cooling units are rated for various size rooms, the thermal load may require a larger sized cooling unit.  Thermal load may be affected by glass in the cellar, room positioning or other factors.  Please let a Rosehill Wine Cellar rep make some suggestions for you if needed.

All air-cooled refrigeration equipment requires fresh air intake to dissipate the heat generated by the cooling unit. The fresh air intake CANNOT come from the wine cellar space - it must come from space outside the cellar. Designed for indoor use only, 1800XT-ECX units can operate in environments ranging from 95F to 40F out of the box. To operate the unit in colder temperatures, please see modifications listed on the Options & Upgrades tab.

1456 SENSIBLE BTUH @ 55F.
CellarPro 1800XT-ECX cooling units (1/6 Ton Nominal) are suitable for small wine cellars (up to 250 cubic feet), commercial applications and wine cabinets located in garages (in temperatures ranging from 50-95F).

*Assuming R19 insulation throughout the cellar, 55F inside the cellar and 85F outside the cellar.

The cooling unit plugs into a standard wall outlet. The components of the cooling unit draw 3 amps, and the electric outlet on the side of the cooling unit also is rated for 3 amps. We recommend using a surge protector rated at 15 amps or more.

• Weight: 60 lbs

  Power/Rating:
  115V AC / 60 Hz
  Compressor Amps:
  - Running: 3 Amps
  - Startup: 20.1 Amps
  - Total Watts: 263
  - Requires: Dedicated 15-Amp Circuit
  - Recommended: Surge Protector
  Decibels: 47 dBA (Rear)

Large Item Shipping: Additional Shipping charges may be charged for accessory items ordered on their own without the cooling unit. Rosehill Reserves the right to contact you should shipping charges end up substantially higher than advertised on our website.  You will have an opportunity to not complete your order at that time.

For CAD customers - Shipping Charges for importation, brokerage, duties are extra might be extra, however you will be contact by a Rosehill Customer Service Representative to discuss it further. Local delivery included.

A limited 2-year product warranty is offered entire system from date of purchase.

Cellar Pro Standard Warranty

IMPORTANT NOTE: Be sure to have the installing technician complete the CellarPro checklist upon installation. You will then send this to Cellar Pro to activate your warranty.

Cellar Pro 1800 Owner's Manual
Cellar Pro 1800 Configuration Options
Cellar Pro Cooling Systems - Specs
Cellar Pro Cooling System 1800H Houdini - Specs
Cellar Pro Cooling System 1800H Houdini - Configuration Options
Cellar Pro Cooling System 1800H Houdini - Owners Manual
Comparison chart of Features, Performance, Design, and Components

Mounting Guide (Clips)
Mounting Guide (Shelf)

Front, Rear and Sides Dimensions
Top Dimensions
Bottom Dimensions
