TTW01B Classic - Through the Wall Wine Cellar Cooling Unit
Through November 14, 2026, Rosehill Wine Cellars will hold current Canadian pricing on select US manufactured wine cellar cooling systems and absorb the additional tariff costs. Secure your unit at today’s price before pricing is reassessed.
Description
This through-the-wall wine conditioning system is ideal for small residential wine cellars.
The TTW01B Classic is a 60Hz system, which is standard in the majority of North America. Unit capacity is 830 – 1485 BTU.
This unit is also easy to install, and can be installed on your own without the support of a contractor.
Note: This model is not rated for exterior use.
Although the cooling units are rated for various size rooms, the thermal load may require a larger sized cooling unit. Thermal load may be affected by glass in the cellar, room positioning or other factors. Please let a Rosehill Wine Cellar rep make some suggestions for you if needed.
TECHNICAL SPECS
- Model TTW01B Classic
- Line Frequency 60 Hz
- Capacity 830 – 1485 BTU
- Length 25.8"
- Width 14.1"
- Height 15.8"
- Weight 58 lbs
- Electrical 120/1/60
- Plug Type B
- Installation Level Do-It-Yourself
Additional Information
Wine Guardian Through-the-Wall cooling units offer excellent airflow for your wine cellar, which assists to maintain optimal temperature & humidity — all this with quiet operation.
Self-contained, ductless, air-cooled system with integral local user interface controller to control temperature and monitor humidity. System ships complete with an easy-to-install mounting sleeve and deluxe power cord. The TTW01B Classic can also be equipped with many options and accessories, including remote sensors.
Classic TTW01B Key Features
Unrivaled Energy Efficiency: Optimized for maximum energy efficiency, the TTW can save you hundreds in energy costs and meets US DOE efficiency standards.
Whisper-Quiet Operation: Designed to limit vibrations and operational noise that disturb the ambience of your wine space, TTWs can be as quiet as 49 dB at 6 feet (2 meters).
Fail-Safe Protections: The TTW’s advanced fail-safe features protect your system and cellar from damage.
Precise Temp & Humidity: The TTW can achieve temperatures ranging from 55°F (13°C) to 58°F (14°C) and a relative humidity of 55%–65% with an optional free-standing humidifier.
DIY Installation: Installing the TTW is as simple as sliding the unit through the wall sleeve or mounting brackets. A licensed contractor is not required.
Eco-Friendly Refrigerant: Wine Guardian TTWs employ refrigerant with a low global warming potential in compliance with U.S. environmental regulations.
What's Included?
- Mounting Bracket
- Pre-charged Unit
PRODUCT MANUALS
If you would like racking as well, we will be happy to customize a design and obtain a shipping quote for your entire order. Checkout Our Racking Options
PROTECTING YOUR CELLAR YEAR ROUND
A wine cellar cooling system is an investment in both your collection and your space. Rosehill Wine Cellars offers professional servicing and preventative maintenance plans designed to keep your cooling system operating efficiently, reliably, and at the proper cellar conditions.
Regular service can help identify potential issues early, maintain consistent temperature and humidity, and extend the life of your equipment. Ask our team about available service plans for ongoing care and peace of mind.
